Rashid Metals, located in Muscat, Oman, stands out as a leading manufacturer and supplier of top-notch copper products, with a special focus on Copper C11400 Bars and Rods. The company prides itself on its dedication to excellence and precision, catering to a diverse array of industrial and commercial sectors. By blending cutting-edge manufacturing techniques with rigorous quality control, Rashid Metals guarantees that every product is durable, reliable, and performs optimally. With a solid reputation built on trust, they serve clients throughout Oman and the Gulf region, consistently delivering superior copper solutions that align with international standards and adapt to the ever-changing demands of modern engineering and construction.
Copper C11400, often referred to as electrolytic tough pitch (ETP) copper, boasts an impressive 99.9% purity with very low oxygen content. This makes it an excellent choice for electrical and thermal conductivity, along with high corrosion resistance and remarkable ductility. In terms of mechanical properties, it has a tensile strength ranging from about 210 to 250 MPa and a yield strength between 70 and 200 MPa, with elongation reaching up to 50%. This unique blend of strength and flexibility allows it to be bent and formed without losing its integrity, ensuring dependable performance in electrical, industrial, and mechanical applications where both conductivity and durability are essential.
| Specification | ASTM B187, ASTM B301 / ASME SB187, SB301 |
| Size Range | 3.17 MM TO 350 MM DIA |
| Length | Random, Fix & Cut Length |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
| Melting Point – Liquidus°F | 1980 |
|---|---|
| Densitylb/cu in. at 68°F | 0.322 (1) |
| Specific Gravity | 8.91 (2) |
| Electrical Conductivity% IACS at 68°F | 100 |
| Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F | 224 |
| Coefficient of Thermal Expansion 68-57210 to -6 power per °F (68 – 572°F) | 9.8 |
| Specific Heat CapacityBtu/ lb /°F at 68°F | 0.092 |
| Modulus of Elasticity in Tensionksi | 17000 |
| Modulus of Rigidityksi | 6400 |
Copper C11400 Bars and Rods have good thermal conductivity but are not ideal for high-temperature applications. They are best used at temperatures up to 200°C to prevent softening and degradation.
Yes, Copper C11400 Bars and Rods are fully recyclable. The material retains its properties after recycling, making it an eco-friendly option for sustainable industrial use and reducing environmental impact.
Copper C11400 Bars and Rods are naturally resistant to corrosion in many environments. However, in harsh conditions such as marine or acidic environments, additional protective coatings may be recommended.
Copper C11400 Bars and Rods find extensive use in electrical, industrial, and mechanical applications thanks to their superb conductivity and resistance to corrosion. They are perfect for crafting electrical components, busbars, connectors, and grounding systems. In industrial environments, they play a vital role in plumbing, heat exchangers, and machinery parts that require both thermal conductivity and strength. Their ductility and malleability also make them ideal for custom fabrication and structural uses. Highly sought after in the construction, electronics, and energy sectors, Copper C11400 Bars and Rods ensure reliable performance in various settings, both indoors and outdoors, providing long-lasting efficiency and safety.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
